These contour plots a not useful to have a quick insight on the analysis results. Hence presenting the contour plots in the design reports is not a good practice. A way out is to use section cut techniques which are available in most of the FEM packages. We can defined the section cuts according to the strips defined in the ACI 318 code. The output for the strips shall be the more familiar bending moment and shear force diagram plotted along the length of the strips. An extra advantage of the diagrams will be that a diagrams (bending moment, shear force and axial force) for different load combinations can be drawn on one plot simultaneously, hence easy to determine the governing load combinations. Note:- FEM package like SAFE has built in features similar to section cut, that’s why you get analysis results for strips.

Example Consider a reinforced concrete flat plate rested over 3m high columns. The structure consists of two bays in x-direction and two bays in y-direction. The bay width in x and y-directions is 5m. The slab thickness is 175mm.

The column size is 500mm square. The slab is loaded by self weight of the slab and live load of 5 KN/m2. Design the flat plate using section cut techniques in SAP2000. (Since the flat plate is symmetrical in two directions, one needs to define section cuts in one direction and for half the slab) Figure 1: Example reinforced flat plate with the section cuts marked for column strips and middle strip Explanation The slab can be divided into column strips and middle strips, according to the ACI-318 code. Since the flate plate is symmetrical in two directions, one needs to define strips in one direction and for half the slab. Hence two column strips and one middle strip is marked on the figure 1. Now the section cuts are to be defined to capture the total force (Shear force, bending moment and axial force) in the width of the strip.

For this purpose, 5 section cuts are to be defined in each span for each strip (10 section cuts per strip). The section cuts are numbered in the figure 1. One can use the option Draw ->Section cut. But the output is not saved for future use, if this option is used. There is another way to define section cuts using Define ->Section cuts By using the Define ->section cut option the output for the forces on the section can be recalled and processed later on. The section cut has to be defined using Quadrilateral cutting plan.

It is preferable that the cutting plane be kept slightly away from the nodes, because sometimes SAP2000 is unable to process the output for the section cuts exactly at the nodes, and report a zero values. Figure 3 shows the data for section cut definition for column strip 1 for section cut #1. Note that the slab is at elevation 3m in z-direction. Therefore the cutting pane is defined such that the slab is cut by the plane. Figure 2: Define section cut dialogue box Figure 3: Section cut definition for column strip section cut #1 Similarly 10 section cuts are defined for each strip. The output for the section cuts can be called for all the load cases and combinations and processed.

Using the menu Display ->Show Tables ->Structure Oputput ->Other Output Items ->Section Cut Forces Analysis, the section cut forces can be displayed Figure 4: Section cut forces display Figure: 5 Section cut forces The section cut forces can be exported to Excel by using Export current table ->To Excel option In Excel the forces diagram for the strips can easily be drawing for any load combination by little processing of data. For this example M22 gives the bending moment about y-axis, and F33 gives the shear force along the length of strip. The outputs for the three strips are given in Figures below Figure 6: Bending Moment and shear force diagram for Column strip CS1 Figure 7: Bending Moment and shear force diagram for Column strip CS2 Figure 8: Bending Moment and shear force diagram for Column strip MS1 NOTE Always cross check the forces resulting from Section Cut.

The sign of the forces at most of the occasions has to be corrected manually. (This is pretty easy to do). You have to take care that what section forces report you need on the right and which sections should report on the left. After running the structural models they create numerous analysis files with very strange file extensions.

Here I am talking about CSI softwares; ETABS, SAFE and SAP. These analysis files contain information about matrices and analysis results. More information about the file extensions can be found on CSI official webpage: or When sending the model files to someone you dont need all those temporary analysis files rather just 2 files; one model file and another its text file. Why we need to delete the files? Well, one thing is there are lot of files which we dont recognize, and the major issue is they take too much of space. A single model may be upto 10MB or less or more, but after analysis, the folder size reaches sometimes upto 1GB, using hard disk resources.

So its not wise to just leave them as is because once you have model file you can get the results on any machine after running it. For example for a simple model! An increase of about 62 times! Deleting the Files 1) From program To delete the analysis files of the model, there are many ways and techniques:- Open the model, goto File>Delete analysis files>There are 2 options; one for deleting analysis files of that model only and another to delete files of all the models in that specific directory. Here it can’t delete the files of models in sub directories. Just imagine if you have a large project containing many buildings having at least 2 models, all in separate directories, so would have to open all of them one by one and delete files this way.

2) Manually Deleting the Files Another method is to search and delete the files yourself. Unfortunately, I could not find on internet a complete list of all the extensions of analysis files. So I just created sample files for each of the program and then converted by some means those extensions into a text file. I will for your convenience put all those extensions here. So just goto windows search explorer and just copy paste the extensions text string the file name box of search window and delete all the files in one go. If I have missed some extensions of mixed it with other programs, please correct me. 3) The best method While writing this article, I came across a very interesting method to do all that crap.

There is file calledEat.bat in ETABS and SAP program files. When I opened these files in MS DOS, I found out that this DOS files deletes all the analysis files in that directory and you can get the list of all the extensions of the files if you try to edit it. Well that would be the official extension list of analysis files from CSI. The extensions I published below were extracted by me so they miss some extensions. I will later update those. This Eat.bat is found in ETABS and SAP folders but not in SAFE. I dont know why CSI people havent included this in SAFE.

So I came up with an idea to modify the program so that it can do following:- 1) Delete all the analysis files, not just in that specific directory rather in all sub directories too and for all programs like ETABS, SAFE and SAP. I will just add all the extensions and a switch for deleting files inside other directories:- ERASE /S /Q * Soon it will also be available in standard EXE format. Autodesk Revit - a program for the design and construction of buildings and structures.
